Strata Worldwide

StrataSorb is a super absorbent polymer designed for removing nuisance water and organic fluids. It is a powder-like material that absorbs liquids and converts to a light-weight solid.

Turning fluid into a solid makes it much easier to handle. Can be manually or mechanically removed.

StrataSorb is non-toxic and non-hazardous. It can be safely incineration with no PCB or dioxin formation. Safe for deposit onto belt lines and into landfills.

Mixing ratio 300 to 1 – 1lb powder absorbs approximately 36 gallons (300lbs) of clean water.

Strata AC Flow stop is a super absorbent emulsion-based polymer that retains large quantities of water in mining, tunneling and civil engineering applications

Absorbing excess water in running sands, EPBM cutterhead, and conveyor applications. It can also be used for borehole stabilization and as a mud conditioner

Non-toxic for the environment

Single component

Very fast-reacting hydrophilic resin

Durable in wet and dry conditions

Strata 500 US is completely unreactive to water, making it ideal for sealing against and diverting water flow

Injected under pressure, Strata 500 US has high flowability, which enables it to seep into tiny rock fractures and porous soils to solidify and fortify the entire structure

Strata 500 US is ideal for ground stabilization, roof bolt anchoring, soil nails, rock bolts, rebar, and hollow bar applications

Two-component, non-expansive urea silicate resin

A non-toxic, low-viscosity acrylic grout used for sealing and soil consolidation

Forms a strong, flexible gel when mixed with activators

Works in wet or dry conditions and remains durable and waterproof

Stop water inflow or leaks in tunnels, mines, and underground works

Stabilize soil or rock by filling cracks, voids, or porous substrates

Injectable through drilled holes, Tube A Manchette (TAM) or treme pipes using standard grouting pumps

Non-toxic, non-flammable, and acrylamide-free

Extremely low permeability (excellent waterproofing)

Adjustable setting times from a few seconds to an hour plus

Remains flexible—expands slightly in saturated soils and remains stable in dry soils, without cracking

AC52 or AC42 Resin – acrylate resin

TEA 85 – liquid activator (controls gel time - between 10s and 60+ min)

SP Powder – initiator (starts the reaction)

KF Additive – time-control agent

Mix parts A and B in a 1:1 ratio using a two-component stainless steel pump

Store sealed, away from sunlight, at 0–30 °C, up to 6 months

Use stainless steel or plastic containers

Spray-on liner that is impermeable and unaffected by water. It begins preventing water ingress upon application. Used in NATM and SEM as a seamless, fully bonded waterproofing membrane between two layers of shotcrete or cast-in-place concrete

Resin-based spray-on liner that meets highest waterproofing categories - ITA and BTS specifications
